LK9 with Raise/Lower Mechanism

Slim-Line LK9-106-HHS

LK9-HHS-106 light cross system

Advanced Raise/Lower Mechanism with Enhanced Aerodynamics

The LK9-HHS-106 represents our premium traffic light solution, featuring an innovative raise/lower mechanism combined with exceptionally low wind resistance. This intelligent design maximizes visibility when deployed while minimizing drag and stress on your vehicle when retracted.

Superior Illumination Technology

Our system showcases an extremely flat aluminum panel with a sleek black backplate housing 9 high-performance LED lamps. Each Ø200 mm lamp contains 30 precision-engineered LEDs, providing unmistakable signals visible from extraordinary distances in all weather conditions.

Engineered for Durability

The raise/lower mechanism is constructed from premium heavy-duty aluminum and steel profiles, ensuring reliable operation and exceptional durability even in the most demanding environments. This robust construction maintains stability during operation while providing the convenience of adjustable positioning.

Versatile System Integration

The LK9-HHS-106 is designed with flexibility in mind, offering seamless capability to mount and connect light bars and external flashers directly to the frame system. This versatility allows for customized configurations to meet specific operational requirements without complex additional installations.

Simplified Installation Process

Despite its advanced functionality, the LK9-HHS-106 maintains remarkable installation simplicity, requiring just a 4-wire cable connection to the cabin (positive, negative, and 2 control wires). The system includes an intuitive backlit control panel and a standard push-button remote control with cable.

Intelligent Adaptive Lighting

The integrated photosensor automatically adjusts brightness across a minimum of 5 levels based on ambient light conditions, fully complying with Road Directorate requirements. This smart feature ensures optimal visibility while maximizing energy efficiency and extending component life.

Talk to an expert Brochure
LK9 1-1
LK9 voll
LK9 außen
NY Fjernbetjening LK9
LK9 1-1 LK9 voll LK9 außen NY Fjernbetjening LK9
LK9 1-1

SKU: 2091112323

Advanced Raise/Lower Mechanism with Enhanced Aerodynamics

Technical Specifications:
  • Weight: 29 kg including frame system and motor
  • Number of lamps: 9 pcs. (Ø200 mm)
  • LEDs per lamp: 30 pcs.
  • Material: Aluminum
  • Panel dimensions: 1060 x 1060 x 35 mm
  • Light class: CE EN12.352 L8H tested and approved
  • Power requirements: 12V
  • Average consumption: 3.5A
  • Control system: RS485 canbus
  • Control interface: Backlit control panel
  • Included remote: Push button with cable

Experience the LK9-HHS-106 – where cutting-edge engineering meets practical design for superior traffic signaling with exceptional aerodynamic performance.
